型号 Model | HF-20 | HF-30 | HF-40 |
最大加工长度 Max length | 2800mm | 2800mm | 2800mm |
每排夹具 Each row fixture | 6支(pcs) | 6支(pcs) | 6支(pcs) |
拼板最大厚度 The maximum thickness of puzzle | 100mm | 100mm | 100mm |
减速马达 Gear Motor | 2HP*1 | 3HP*1 | 3HP*1 |
机械总动力 Machinery total power | 12HP | 13HP | 13HP |
油压枪 Hydraulic gun | 2套(sets) | 2套(sets) | 2套(sets) |
自动化液压系统 Automation of hydraulic system | 1套(sets) | 1套(sets) | 1套(sets) |
最大加工宽度 Maximum working width | 980mm | 980mm | 980mm |
夹具数 Fixture Number | 20排(rows) | 30排(rows) | 40排(rows) |
中压油压系统 Medium pressure hydraulic systems | 5HP*2 | 5HP*2 | 5HP*2 |
减速箱 Gearbox | WPA155#*1 | WPA155#*1 | WPA175#*1 |
旋转速度 Spinning speed | 0.8rpm | 0.8rpm | 0.8rpm |
压料气缸 Nip cylinder | 2支(pcs) | 2支(pcs) | 2支(pcs) |
工作气压 Working pressure | 0.7 Mpa | 0.7 Mpa | 0.7 Mpa |
