DOUBLE CNC DOUBLE ENDED TENON MACHINE(WITH PROCESS LINE)

Discover the DOUBLE CNC Double Ended Tenon Machine with integrated process line, designed for high-precision woodworking. Ideal for efficient, accurate, and consistent tenoning, this advanced CNC machine enhances productivity in woodworking applications. Perfect for manufacturers seeking reliable and versatile equipment for creating double-ended tenons with ease.
Description Warranty Info


加工榫间距
Processing tenon spacing
190mm-2100mmX轴伺服功率
X-axis servo power
1.5KW*2pcs
加工榫宽度
Processing lenon width
1-200mmY轴伺服功率
Y-axis servo power
1.5KW*2pcs
加工榫厚度
Processing tenon thickness
1-70mmZ轴伺服功率
Z-axis servo power
0.4KW*2pcs
加工榫长度
Processing lonon length
1-40mmU轴伺服功率
U-axls servo power
0.4KW*2pcs
水平角度
Horzontal anglo
-20°+45°主轴转速
Spindle speod
8000-12000 r/min
重直角度
Vertical angto
-15° +45°倒角主轴转速
Chamlering spindie speod
10000-18000 r/min
工作气压
worlung pressure
0.7 Mpa电压
Voltage
380V
主轴功率
Main whah power
5.5KW*2pcs总功率
Total work rate
19.35KW
倒角主轴功率
Chamlering spindio power
2.2KW*2pcs外形尺寸
outline Dimension
4500mm*2250mm*1780mm
横轴伺服功率
Horuortal axis servo power
0.75KW*1pcs机械重量
Mechanical weight
3000KG
