CNC MITER MACHINE
CNC MITER MACHINE CNC MITER MACHINE CNC MITER MACHINE

CNC MITER MACHINE

Our CNC Miter Machines, designed for high-accuracy woodworking. Perfect for cutting intricate miters with speed and consistency, our advanced CNC technology ensures superior results for any woodworking project. Upgrade your workshop with a CNC miter machine and experience the difference in quality and productivity.
Contact Us
Description Warranty Info


CNC MITER MACHINEHF-CNC 1200B
电源  Power source380V/50HZ
榫头刀主轴转速 Spindle speed of tenon cutter12000r/min
榫头刀主轴功率 Spindle power of tenon cutter5.5KW
榫头刀主轴规格 Size of tenon cutterΦ30mm
榫眼轴转速 Mortising shaft speed18000r/min
榫眼轴功率 Mortising shaft power3.7KW
榫眼刀柄夹头 tool shank chuck for mortiseΦ3mm/16mm
榫头加工宽度 Tenon processing width0-140mm
榫头加工厚度 Tenon processing thickness0-80mm
榫头加工长度 Tenon processing length6-45mm
工作气压 Working pressure0.7 Mpa
榫眼深度 Mortise depth 0-60mm
外形尺寸 Overall dimension2120*1490*1810mm
